ATMEGA Hex-v2 22.9.0 is the new generation of vagcom vcds obd2 diagnostic interface for vag vehicles. VCDS Hex-v2 USB Interface VAG 20.4.2/19.6.1 support 5M baud rate communication, it is ensure the integrity and efficiency of data transmission..  Atmega162 HEX V2 VCDS 20.12/18.9 /19.6  full active cable For VW Audi Seat Skoda,it is BUG fixes and improvements support Windows 10 system.

ATMEGA VAG HEX-V2 Vag 20.4.1 USB interface VCDS HEX V2 20.12.0 Multilanguage For VW Audi Seat Skoda
DIY Atmega162 HEX V2 VCDS 17.8.1/ 18.9.0/19.6.1/19.6.2 full active cable For VW Audi Seat Skoda VAG HEX V2 support reprogramming, OBD2cartool DIY Atmega162 HEX V2 with originial and full chips!!!

Special thanks to the great engineer kolimer

VCDS HEX V2 Multilanguage Vag 17.8/ 18.9 Choose:

Option 1: HEX V2 Vag 18.9 English Or En VAG COM Release 19.6.1 or VAG COM Release 20.4.0 Newer 20.4.1
Option 2: HEX V2 Vag Deutsch 18.9 German Or DE version VAG COM Release 19.6.1 Newer 20.4.1
Option 3: HEX V2 Vag French 18.9 Français Or FRM version VAG COM Release 19.6.1 Newer 19.6.2
Option 4: HEX V2 Vag Romanian 18.9 Română Or ROJ version VAG COM Release 19.6.1 Newer 20.4.1
Option 5: HEX V2 Vag Spanish 18.9 Español Or EST version VAG COM Release 19.6.1 Newer 20.4.1

Option 6: HEX V2 Vag 17.1.3 Czech or 18.9 čeština

Other languages pls leave messages when you make order. option 18.9 leave message free update to 19.6.1

Note: This DIY ATMEGA VAG HEX-V2 work on the newer VCDS 20.12.0 Release, but stable version is VAG COM 20.4.1 and 19.6.1 for car before 2017,you could working with VCDS 22.3.0 release EN, but not with full function.

EN English 22.9.0 Released
DE German 20.4.1
ROJ romanian 20.4.1
FRM French 19.6.1
NEZ Danish 20.4.1
AER Sweden 19.6.1
HGJ Hungarian 20.4.1
CN Chinese 19.6.1
ITT Italian 19.6.1
EST Spanish 19.6.1
AKP polish 19.6.1
RUS Russian 19.6.1
PTT Portuguese 19.6.1

Note: Import taxes and duties are buyer's subject to pay, if need help to clean customs could contact with us.The latest version of the software does not mean that it is the best. Some VINS can be supported on the old software, New software may not be supported. but our interface is compatible with lower versions to 17.1...

 If your car is made before 2017, it is suggest order this HEX CAN cable will better.

If your car is MQB A0 Platform or MY2018+MY2021 , recommend this version:

DIY VAG COM 22.9.0 HEX V2 Interface 22.3 MQB HEX V2 Update unlimited VIN Diagnostic Cable for VW Audi Seat Skoda. It is support good on MQB and MQB A0 platform

HEX-V2 VAG 17.8.1 / 18.9.0 stable version highlight:

Vag Hex v2 support for CAN-FD.
Support reprogramming newer language and version by your self. It is DIY version, Not work friendly with MQB platform.
High quality original brand new IC production
After installation has been activated to support all systems diagnostics (including K1,K2,CAN,UDS)
VAG HEX-V2 17.8.0 / 18.9.0 support 5M baud rate communication, it is ensure the integrity and efficiency of data transmission.

Note: if you want stable version vcds upgradeable interface, please check this one:

Vag com 20.4.0 HEX CAN USB Interface VCDS 18.9.1 online update version 16 multilanguage

OBD2cartool.com vagcom 17.8.1 vcds 17.8.1 english tested screen:

ATMEGA Hex-v2 VCDS 17.8.0 / 18.9.0 Features:

Language: Multilanguage
Software Version: VCDS 17.8.0 or vag com 18.9.0
Firmware Version: 1.96
Supported Vehicle List: For AUDI VW SEAT SKODA
Chip Edition: ATMEGA162 + FT232RQ + 9241 + 16V8B +ATA6561（This period will use more expensive NXP CAN controller replace the ATA chip)
System requirement: Windows XP, Vista, 7, 8 and 10(32-bit and 64-bit)
(It does not support Windows 95, 98, ME, and NT4 operating system)

VAG/VCDS HEX-V2 17.8 multilanguage PCB:

1. Four-layer circuit board, high quality Components
2. VAG/VCDS HEX-V2 with FT232RQ + 16V8B + ATMEGA162
3. Dual 9241 chip ensures K-line communication stability
4. obd2cartool.com Exclusive CAN-FD (5M) , VAG/VCDS HEX-V2 support 5M baud rate communication

ATMEGA Hex v2 VCDS 17.8.0 New added functions:

-Support for MLB2 platform cars (HEX-NET interface recommended)
-Support for 2016 and early model cars
-Greatly expanded the amount of DTC Freeze-Frame data dsiplayed
-Improvements in Advanced Measuring Value Selection Window
-Display of factory identifiers instead of arbitrary location numbers
-Support for Six-Digit security access codes
-HEX-NET Turbo and other speed optimizations
-Optimized low-level timing routines and CPU core affinity
-Major firmware enhancements for HEX+CAN and Micro-CAN interfaces
-Improved UDS mapping speed and reliability when subchannels are present; progress indicators.
-Fixes SRI reset in newer Crafter instruments.
-New ASAM data and Label Files
-Support vehicle list: For AUDI VW SEAT SKODA


HEX V2 Vagcom 17.8.0 / 18.9 New Features:

Auto Scan 1001.01
1. Control module unit information
2. Read fault codes 004.01
3. Output test 005
   Selective output test 005
4. Basic settings 006
5. Clear DTCs 004.10
6. Close control module 022
7. Pairs of coding control module (brush hidden) 007 (service 1A)
   008 (Service 22) From the station control module 007 coding (service 1A)
   008 (Service 22) Read measured value block 08 010.02 (KWP1281)
8. Advanced measurement reading
9. channel read 010.01
10. matching 012 014 (long)
11. Log (Known under KWP-2000 * Coding II) 015.01
12. View readiness 020.01 Guided ready state settings
13. security access 015.02
14. All supported DTCs
15. Common OBD-II function
16. Fault environmental data
17. Dual K-Line Support 7-PIN code 020.07
18. Upgrade to the latest fault code library
19. Direct CAN line diagnosis (Need to support diagnostic cables CAN line diagnosis)
20. Modes of transport 1001.03 (on)
    1001.04 (off) (Need to support diagnostic cables CAN line diagnosis)
21. Advanced measurement block
22. Support for dual engine control module

Compared to the previous version, the VAG 17.8 main changes is BUG fixes and improvements.

Atmega162 Hex v2 Vag 17.8.0 Basic functions

00 Auto Scan
01 control module unit information
02 read fault codes
03 Output Test
       Selective output test (only for KWP-2000 *)
04 Basic settings
05 clear DTCs
06 Close Control Module
07 pairs of coding control module
       Slave control module for coding (only for KWP-2000 *)
Read measured value block 08
09-channel read (applies only to KWP-1281 *)
10 matching
11 Log (known under KWP-2000 * Coding II)
15 View Ready
16 security access (only for KWP-2000 *)
18 All supported fault codes (only for KWP-2000 *)
33 Common OBD-II function

VAG/VCDS HEX-V2 17.8.0 Packing List:

1 x HEX-V2 VAG 17.8 diagnostic cable
1 x CD with VCDS 17.8 software or vag com 18.9.0( Leave message for newer 19.6.0)
